Super Capacitor Module

 /Start-stop Use Supercapacitors 16V 100F

Start-stop Supercapacitor
Start-stop Supercapacitor Start-stop Supercapacitor Start-stop Supercapacitor

Start-stop Use Supercapacitors 16V 100F

The 16V module is mainly used in idling start-stop systems, military reserve starting power, wind power pitch systems, and smart grids.

  • Brand:

    GTCAP

  • shipping port:

    Shanghai

  • Model:

    GTSM-16V100FUS

  • value:

    100F

  • votage:

    16V

  • Feature:

    Large power,Compact, fully enclosed splash proof

  • MOQ:

    10pcs

  • Payment:

    T/T,L/C, Western Union,Paypal,Alipay

  • Color:

    Black

  • Lead Time:

    within 10days after payment arrived

  • product origin:

    China
Inquiry now
Products description

Start-stop Use Supercapacitors 16V 100F


Green Tech has developed a variety of supercapacitor modules (16V, 32V, 48V, 350V etc.) and also has the ability to customize to client specifications.

Features

The 48V module is widely used in new energy buses, passenger cars, and rail transportation. It recycles energy to reduce exhaust emissions with fuel saving rate between 20%-35%, so as to improve power and motor vehicle performance and extend vehicle lifespan.

The 32V module is widely produced for aircraft starting, heavy vehicles, unmanned aerial vehicles, armored vehicles, and tank-starting. It effectively conserves system weight and space while improving system adaptability and maneuverability.

The 16V module is mainly used in idling start-stop systems, military reserve starting power, wind power pitch systems, and smart grids. It improves system adaptability and maneuverability, and reduces system response time.

Typical Application

Automotive, Industrial, Telecommunications, Railway transportation, Uninterruptible Power Supplies(UPS)

Specifiacation Data

GT PN.

Cap.

Vol.

Max. ESR(mΩ)

Max. Continuous Current

(A,ΔT=40℃)

Max.Peak Current

1second (A)

Leakage Current(mA)

@25℃ after 72hrs self discharge

Energy Storage

(Wh)

Energy Density

(Wh/kg)

Weight

(kg)

AC

1KHz

DC



GTSM-16V100FUS

100F

16V

20

25

25

270

1

3.56

1.42

2.0

 Rated Voltage

 16VDC

 Max. Operating Voltage

 17VDC

 Capacitance Tolerance

 -10%~+20% (25℃)

 Operating Temperature

 -40℃~+65℃ △C< initial capacitance 20%,△ESR< initial ESR 50%(25℃)

 Storage Temperature

 -40℃~+70℃

 Use Life(1500hrs @65℃@16VDC)

 △C< initial capacitance 30%,△ESR< initial ESR 100%(25℃)

 Storage Life (2years @70℃ non-load)

 △C< initial capacitance 30%,△ESR< initial ESR 100%(25℃)
